Performance Features:
The main large parts of the machine tool: the base, workbench, column, bed saddle, and spindle box are all made of high-quality resin sand molding and high-strength cast iron. They have a complete heat treatment process to eliminate residual stress and arrange sufficient reinforcement plates to ensure that the whole machine has sufficient strength, rigidity and high stability; they use Taiwan's original heavy-load linear guide rails, which have strong rigidity and good dynamic accuracy; the three-axis transmission uses Taiwan's grinding double-nut ball screws, which are compact in structure, smooth in motion and high accuracy; the highly rigid Taiwan's spindle is lubricated by grease, which can ensure that the spindle bearings are constant and reliable lubricated; the base adopts a large casting tray structure, which has good waterproof performance.
Technical parameters:
| project | unit | VMC1160 |
| X-axis stroke | mm | 1100 |
| Y-axis stroke | mm | 600 |
| Z-axis stroke | mm | 600 |
| Workbench size (length x depth) | mm | 1200×600 |
| Maximum load on the workbench | kg | 1000 |
| T-shaped groove (number of grooves × width × pitch) | mm | 5×18×125 |
| Spindle taper |
| BT40 |
| Spindle power | KW | 11/15 |
| Maximum spindle speed | rpm | 8000 |
| Fast movement speed (X/Y) | mm/min | 36/36/24 |
| Fast movement speed (Z) | mm/min | 18000 |
| Cutting feed | mm/min | 1-8000 |
| Feed motor | NM | 20/20/20 |
| Distance from the spindle nose to the workbench | mm | 140-740 |
| Distance from the center of the spindle to the column guide rail surface | mm | 650 |
| Maximum tool diameter | mm | 78/120 |
| Maximum workbench length | mm | 300 |
| Maximum workbench weight | kg | 8 |
| Positioning accuracy | mm | ±0.0075 |
| Repeat accuracy | mm | ±0.005 |
| Machine tool weight (approximately) | kg | 7000 |
| External dimensions | mm | 3400×2480×2960 |
